Automatic Bottle Filling Machine 16 Pieces Heads 7000BPH for 500ml CGF16-16-5
Rotary Pure Water Filling Machine with Sealing for Plastic Bottle of Best Quality
Description:
1.Automatic Bottling 3 in 1 Water Filling Machine adopt Rinsing/Filling/Capping 3-in-1 technology, PLC control, Touch Screen, it is mainly made of SUS304.
2.It is used for filling kinds of non-carbonated water, such as still water,mineral water,flavored water,spring water .
3.Its usual prodcution capacity is 5000bph, 0.3-2L PET bottle is available.
4.Pivotal electrical part use Mitsubishi, OMRON, SIEMENS.
5.Filling accuracy is more or less than 1%.
Quick Detail:
| Name | Water filling machine, water bottling machine, water filler, water filling equipment | Brand Name | StepChina |
| Capacity | 7000B/H for 500ml | Bottle size | from 200ml to 2500ml |
| Function | Bottle washing, water filling, bottle capping | Usage | Bottled water production |
| Operation | Touch screen | Control system | PLC automatic control |
Suitable bottle:
- kinds of PET bottle, size from 200ml to 2500ml;
- bottle cap: screw cap
Specifications:
| Name | Rinsing, filling and capping machine |
| Model | CGF 16-16-5 |
| Material | Stainless steel 304 |
| Production capacity | 7000B/H (500ml) |
| Detail specification |
| Number of rinsing heads | 16 |
| Number of filling heads | 16 |
| Number of capping heads | 5 |
| Applicable bottles | PET bottle,plastic bottle |
| Bottle diameter | Φ55-110mm |
| Bottle Height | 186-310mm |
| Bottle Volume | 200-2500 ml |
| Applicable caps | Plastic screw cap |
| Total power | 2.2 Kw |
| Weight | 3000 Kg |
working process:
Empty bottle------air convyeor------CGF16-16-5-------lamp inspector------labeling machine------inkjet printer------packing machine------palletizer
Applications:
1. Bottled mineral water production.
2. Bottled purified water production.
FAQ:
Q1: Are you a trading company or a manufactory?
A1: We are a manufactory, we supply the factory price with good quality, welcome to visit !
Q2: What’s your guarantee or the warranty of the quality if we buy your machines?
A2: We offer you high quality machines with 1 year guarantee and supply life-long technical support.
Q3: When can I get my machine after I paid?
A3: The deliver time is based on the exact machine you confirmed.
Q4: How can I install my machine when it arrives?
A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.
Model list:
| Model | Capacity |
| CGF14-12-5 | 5000BPH |
| CGF16-16-5 | 7000BPH |
| CGF24-24-6 | 12000BPH |
| CGF32-32-8 | 15000BPH |
| CGF40-40-10 | 18000BPH |
| CGF50-50-12 | 22000BPH |
| CGF60-60-15 | 25000BPH |
| CGF72-72-18 | 32000BPH |
